SDN Detector for Nitrogen Dioxide (NO,)
Reference : SDN
Product code: 21122999
- Detector sensitive to nitrogen dioxide (NO,) particles
- Certified according to UNE 23300 and EN 50545-1 standards
- Service life: 10 years
- Detection via electrochemical sensor
- Installation height: between 1.5 and 2m from the floor
- Coverage area: 200m²
- Power supply: 24 to 35VDC (polarized)
- Average standby consumption: 2mA
- Average alarm consumption: 4mA
- Status indicator via red LED
- Operating temperature: -10°C to 50°C
- Relative humidity: 20 to 93%
- Supplied without base
- Dimensions: 115(Ø) x 60(H) mm
More information
- Recommended installation height: between 1.5 and 2m above the floor
- Supplied without base
- Status indicator: red LED
- Coverage area: 200m²
- Power supply: 24 to 35VDC (polarized)
- Standby consumption: 2mA
- Alarm consumption: 4mA
- Dimensions: Ø 115 x h 60mm
- Humidity: 20 95% RH
- Temperature: -10°C ~ +50°C
- IP rating: IP30
- Service life: 4 years
