SW-104E 4-Port outdoor PoE switch
Reference : SW-104E
Product code: 31600340
EAN code : 8429898030319
- 4 x 10/100Mb/s PoE ports
IEEE 802.3af/at standard
2 x 10/100Mb/s Uplink ports
Long distance mode up to 200m
3 cable glands
IP56 protection rating
ABS plastic material
Operating temperature: -25°C to 50°C (-25°F to 122°F)
Dimensions 146 (W) x 196 (H) x 78 (D) mm
Specifications | |
---|---|
Network interface | RJ45 |
POE ports | 4 |
Uplink ports | 2 |
SFP ports | 0 |
Tube inputs | 3 |
Material | ABS Plástico |
Flanges | No |
Compatibility | IEEE 802.3af/at |
Supported modes | Extended PoE |
Electrical protection | Short circuit,Overvoltage,Overload |
Dimensions - High (mm) | 196 |
Dimensions - Width (mm) | 146 |
Dimensions - Deep (mm) | 78 |
Input voltage (V) | 230Vca |
Included power supply | Yes |
